Technical Specifications
Audio
Codecs
• G.711 A-law, u-law
• G.722 (wideband)
• G.723, G.726, G.729, GSM 6.10 (FR)
Ringtones • Built-in assignable ringtones
Audio quality • Acoustic echo cancellation for local echo (AEC) full duplex
Other features • Comfort noise generator (CNG)
• Voice activity detection (VAD)
Display
Size (inch) • 2.8”
Resolution • 320 x 240 pixel
Type • TFT liquid crystal display (LCD)
Keyboard
Keys • 38 hard keys in total
Keys • 12 keys (standard ITU telephone keypad)
Keys • 4 context sensitive function keys
Keys • 4 SmartLabel keys (with multicolor LED)
Keys • 8 dedicated functions keys: Ok, cancel, DND, message (with red
LED), directory, menu, transfer, hold
Keys • 5 dedicated audio keys: Mute, speakerphone, headset, volume +/-
(rocker)
Keys • 5-way navigation key
Network
specifications
Configuration
• SIP
• SDP
• RTP, RTCP
• DHCP, NTP
• LDAP
• HTTP / HTTPS / TFTP
• L2TP
• TLS V1.2
• SIP REFER method (RFC 3515)
• rport (RFC 3581)
• Secure web server / client (HTTPS)
• ENUM
• ICE
• STUN
• SIPS (SIP over TLS), SRTP, SRTCP
• 802.1X Authentication and EAPOL
• LLDP-MED, RTCP-XR
• Password-protected web interface
• Configuration and setup via menu-driven web user interface
• Configuration and setup via menu-driven phone user interface
IP
• Dual Stack IPv4 / IPv6
• VLAN (IEEE 802.1Q)
• OpenVPN
Provisioning
• Automatic loading of settings and firmware via HTTP / HTTPS /
TFTP
• DHCP Options 66/67
• Gigaset Redirect and Provisioning Environment (GRAPE) support
• Plug & Play (PnP) support
• Remote management via TR-069 / TR-069 Annex G (TR-111)
• SIP / PCAP trace
• Syslog
Connectivity
LAN connection
• 2x RJ45-8P8C Gigabit Ethernet port
• Power over Ethernet (PoE)
• IEEE 802.3af, class 2 / IEEE 802.3az (optional via software)
Headset connection • RJ9-4P4C socket (headset available separately)
Handset • RJ9-4P4C socket
• Hearing aid compatible (HAC) handset
Sensor • Hook switch sensor
Interoperability • Interoperable with all major IP PBX platforms
Phonebook
Contacts • LDAP (server-based directory)
• XML browser
Address book • Local directory with 1000 entries
Telephony
VoIP • 6 SIP identities / accounts
• Up to 6 simultaneous calls
Call groups • 3-way conferencing on the phone
Localization • Language, time, dial tone
Other features • Menu-driven user interface
• Multiple language support
Dial functions Functions
• Call diversion
• Caller identification (CLIP)
• Calling Line Identification Restriction (CLIR)
• Call waiting/swapping
• Call history lists for dialed, received, missed, rejected and
deflected calls
• Call completion (busy / unreachable) (if supported by PBX)
• Call park, call unpark (if supported by PBX)
• Speed dialing via function keys
• Hold
• Music on hold (if supported by PBX)
• Mute microphone
• Automatic redial on busy
• Redial (via dialed calls list)
• Auto-answer
• Blind and attended transfer
• Extension monitoring (Busy lamp field), call pickup (if supported
by PBX)
• Intercom
• Multicast paging
• URL dialing
• Local dial plan
• Client matter code (CMC) (if supported by PBX)
Dialing procedure • DTMF in-band / out-of-band / SIP-INFO
Call protection Blocking list • Call blocking (deny list, anonymous calls)
• DND mode (do not disturb)
Dial lock • Keyboard lock
Signaling &
display indications
Incoming calls • Red LED for call indication / message waiting
Power
Power supply • PoE or 5Vdc power adapter (optional accessory), 10 Watts
Input voltage • 5V DC (SELV)
Functions Wall mountable • Yes
Dimensions &
weights Desk phone
• Without foot stand: 205 mm × 185 mm × 40 mm
• With desk stand:
205 mm × 185 mm × 220 mm (high angle 46°)
205 mm × 185 mm × 200 mm (low angle 28°)
• Weight (approximately):
710 g (without footstand)
830 g (with footstand)
Ordering
information
Color • Black
Environmental
conditions
Ambient temperature • 0°C to 35°C (32°F to 95°F)
Storage temperature • -10°C to 45°C (14°F to 113°F)
Humidity • 5% to 95% (non-condensing)
Accessories
EHS adapter • Gigaset EHS Adapter
Power adapter • Gigaset 5Vdc power adapter
Scope of delivery
1x • Desk phone
1x • Foot stand
1x • Corded handset
1x • Quick Installation Guide
